Indutherm Melter & Casting Machine MUV 400

SKU
78-1400-V / 78-1400-VV
Link Copied to Clipboard
$0.00

Specifications
Brand Indutherm
SKU 78-1400-V / 78-1400-VV
Power 10kW (3x400V)
Temp Max 1500°C
Flask Capacity 160mm diameter / 400mm height
Crucible Volume 400ccm = 6Kg Au 18kt
Machine Dimension
(WxDxH)
800 x 500 x 900 mm
(31" x 19.5" x 35.5" inches)
Machine Net Weight  100kg
Link Copied to Clipboard
Priced individually

The MU as vacuum casting machine: MUV series

With the MU series we offer melting machines for many different demands and with crucible capacities from 155 ccm up to 1,200 ccm. The material is molten in open crucibles and poured by hand into the mould.
The V-versions include one or two additional extra-large capacity vacuum chambers. Evacuating the flask immediately after pouring improves the form filling, reduces porosity and avoids oxidation of the hot metal.

Benefits and Features

  • This machine is only to be used for melting and casting of precious metals normally used for the production of jewelry
  • Melting and manual casting processes in gold, silver, brass etc., on MU 200C also steel, beryl copper etc. is possible
  • Very good for casting of very weighty items (artistic sculptures, technical parts)
  • Melting of metal and lost wax casting in only one machine
  • Efficient mass production casting by use of 1 (V) or 2 (VV) flask chambers
  • The V or VV versions have one or two additional extra-large capacity vacuum chambers
  • The short distance between melting and pouring leads to high-quality cast even with filigree parts
  • Will accept flask sizes up to 130mm x 260mm

The MU as vacuum casting machineThe V-versions include one or two additional extra large capacity vacuum chambers. The evacuation of the flask immediately after pouring improves the form filling, reduces porosity and avoids the oxidisation of the hot metal.The MU melting systems are also available as high-temperature melting systems with ceramic crucibles.

Major Applications

Melting and manual casting processes in gold, silver, brass, etc. on MU200C also steel, beryl copper, etc. is possible.

Very good for casting of very weighty items (artistic sculptures, technical parts)
Melting of metal and lost wax casting in only one machine
Efficient mass production casting by use of one (V) flask chambers

Melting Units MU Series
Flexible melting furnaces designed to melt gold and silver alloys and as well as aluminium, bronze, brass a.s.o. Due to the b induction generator up to 15 kW and the low induction frequency the stirring effect of the metal is excellent.

*CAN BE ORDERED FOR USE WITH FLANGED OR NON-FLANGED FLASKS. Major

* Due to the size and/or weight of this item, it must be delivered by freight truck. Upon completing your order, a customer service agent will call you to arrange delivery.


*Vacuum pump is not included


Spare Parts & Crucibles

Item # Product Image Machine Description Purchase Link
SKU
78-1209
MU 200 & 400

Ceramic & Graphite Crucible with for Indutherm MU 200 Melting Machine

Buy Now
SKU
78-1403
MU 200 & 400



 Indutherm Complete Crucible Ceramic & Graphite for (MU 200& 400)

Buy Now
SKU
78-1704
Non-Asbestos Crucible Case For Under Crucible
MU 200 & 400

Non-Asbestos Crucible Case For Under Crucible

Buy Now


indutherm Blue Power Logo  Indutherm Melter & Casting Machine MUV 400  Indutherm Melter & Casting Machine MUV 400  Indutherm Melter & Casting Machine MUV 400  Indutherm Melter & Casting Machine MUV 400
Specification MUV 400 MUV 700 MUV 900 MUV 1200
Temp max. 1500° C
Power max. / electrical connection 10 kW / 3x400V 12 kW / 3x400V 15 kW / 3x400V 15 kW / 3x400V
Crucible Volume 400 ccm 6kg Au 18 ct 700 ccm 9kg Au 18 ct 900 ccm 13kg
Au 18 ct
1200 ccm 18kg
Au 18 ct
Perforated Flask
with/without
Flange
up to ø 160 mm / 400mm h
Temp. measurement by thermocouple Standard
Temperature control Standard
Programs 20
RS 232, Ethernet, USB interface, diagnostic system Standard
GSM-modem for remote service Optional

Product Manual

Packing Qty Priced individually
OEM Parts Yes
