Indutherm MC100V Superior Plus Casting Kit With Optical Pyrometer


SKU
74-929

  • Brand:  Indutherm
  • Model or Style no. :  MC100V (Gold & Platinum Casting)
  • Power:  8.5 kW  3x400V
  • Required Transformer: 208-400V 3PH Step Up (PN 78-4500-T208)
  • Temperature Max:  2000°C
  • Casting Volume:  450g Au 18 ct & 250 g Steel  500 g Pt
  • For Use of Flasks :  ø 80 mm x 100mm  x 120 mm h
  • Dimensions :  20"D x 20"W x 28"H
  • Machine Weight:  120 lbs
  • Shipping Weight:  475 lbs
  • Country of Origin:   Germany
 $49,995.00

Priced as a kit

Total Price
$49,995.00
Indutherm MC100V Superior Plus Casting Kit With Optical Pyrometer
Indutherm MC100V Superior Plus Casting Kit With Optical Pyrometer

The Indutherm casting machine will melt and cast under vacuum with an immersion thermocouple temperature control up to 1300°C or with its optical pyrometer up to 2000°C. A significant advantage of the MC100V casting machine is the vibration mode after the metal has been poured into the flasks to ensure denser castings, plus it has a digital display and casting memories. The MC100V will produce high-quality castings in brass, gold, silver, platinum, palladium, and stainless steel. Accepts flasks up to 80x120mm.

* Due to the size and/or weight of this item, it must be delivered by freight truck. Upon completing your order, a customer service agent will call you to arrange delivery. Hazmat Items may not be combined for International Shipping (ask for details).

* Please note that the following 208V-400V 3PH Step-Up Transfromer, pictured left, is required.  PN 78-4500-T208
