Indutherm Original Graphite Sealing Rod - S-Type w/ Hole


SKU
78-3504-S

  • Brand:  Indutherm
  • Style:   S-Type w/Hole
  • Material:  Graphite
  • Bottom Diameter:  15mm
  • Length:  174mm
  • Metal Capacity:   2kg 14kt Au
  • Temp Max:  1300° C
  • Weight:  0.20-lbs
  • Designed for:  VC400,450,480V, 500, 600, 650V Machines
  • Application:   Indutherm Original Graphite Sealing Rod for Granulating & Casting Crucibles
  • Country of Origin:  Germany
 $39.25

Priced individually

Total Price
$39.25
Indutherm Original Graphite Sealing Rod - S-Type w/ Hole
Indutherm Original Graphite Sealing Rod - S-Type w/ Hole
  • Specifications:

    • Model: Indutherm Original Graphite Sealing Rod for Granulating & Casting Crucibles
    • Application: VC400,450,480V, 500, 600, 650V Machines

  • Indutherm Graphite Stoppers/Sealing rods are designed to "plug/stop" the metal from dropping from the bottom of the crucible until the correct parameters have been reached.
  • Made with a hollow design to accept a thermocouple
  • The "S" style stopper works best with "S" style graphite crucibles, but can also be used with standard shape graphite casting crucibles.
